Where to Lift your Yamaha YXZ Safely

Find the correct lift points for your YXZ and watch step-by-step examples.

Where should you lift the YXZ?

The Yamaha YXZ can be lifted from the suspension as well as the chassis. Click the video with your jack below to learn more. NOTE: Avoid unsupported body panels, high angle components, tie rods and axles.

Common lift points on the YXZ

The Yamaha YXZ features a robust steel chassis and suspension with clearly accessible lift points near each corner. The front lift points include the lower A-arms and skid plate. Rear lift points include the A-arms. There are additional lift points as well. Click a video below to learn more.

YXZ lift point videos

Watch how to safely lift and support your YXZ on the trail.

Electric Jack PRO
▶
Electric Jack PRO
Manual Jack PRO
▶
Manual Jack PRO
Manual Jack Sport
▶
Manual Jack Sport
Scissor Jack
▶
Scissor Jack

Don't see your exact model? Some Yamaha UTVs share similar lift points. Start with the closest match or return to the main guide.

← Back to Lift Point Guide

How to lift your YXZ

Follow these steps for a safe lift every time.

1
Choose where you want to lift

Locate the recommended chassis tube or suspension component nearest to the corner of the vehicle you need to access.

2
Lift with control

Position the jack as suggested, adjusting for your specific conditions and needs. On extremely loose or uneven terrain, you made need to manipulate the ground or add a large base for additional stability.

3
Repair and get back on the trail

Complete your repair - tire change, recovery, or trail fix - then lower carefully and confirm the system you worked on and all parts you touched are secure and in working order before packing up and driving again.

What you need to lift the YXZ

A compact trail jack with at least 18 inches of total lifting capacity and rated for 2,000 lbs. is needed for the Yamaha YXZ. Pair it with a temporary jack stand (hard shell cooler, tool box, spare tire, large rock or log) for any work that requires time under the vehicle. NOTE: we do NOT recommend you ever place your whole body under a vehicle lifted on the trail without proper jack stands.
Shop Jacks & Tools →

Still have questions?

YXZ lift point FAQs

The primary lift points are the lower A-arms and the skid plate. Please watch the video related to your jack for more info.
With the correct jack, you can lift from the lower A-Arm. Please review the video related to your AGM Jack before you do, to learn more about how your jack best interfaces with the YXZ.
The YXZ weighs approximately 1,500-1,700 lbs. depending on configuration. A jack rated for at least 2,000 lbs. is recommended in case you must lift from the low side of the vehicle in an off-camber situation.
For a quick tire swap on the trail, a jack alone can be sufficient. But if the vehicle will be in lifted for any length of time or a body part will be placed under the vehicle always use jack stands.
A compact jack purpose-built for SXS or UTV trail use that works on uneven ground is ideal. Look for one that you can store on your YXZ.
